HEATING, VENTING & AIR CONDITIONING. Work & play in complete comfort, loaded with the features like full color match doors with electric opening tinted windows and door locks, flip-up winshield, and capability you’d expect from our most refined all-weather workhorse.

Features may include:

Class-leading torque, quieter Rotax engines

• HD7, HD9 & HD10

The HD10 engine is class-leading with 69 lb-ft of torque! The break-in period, early maintenance and frequent valve adjustments are all things of the past. The powerpack design delivers an improved riding experience, with less noise & vibration.

Tame the beast

• You set the limits

Sometimes you just have to rein in all the power of this workhorse for seeding, crop spraying or moving cargo. With the new speed limiter available on all Defenders, you’re the one in control. Get ready for peak work efficiency.

Hydraulic Power Tilt Bed

• Unload at the push of a button

Industry-leading cargo box of 4.5 x 6 ft long – with 1,000 lb (454 kg) cargo box capacity, an easy flat-bed conversion and a hydraulic power tilt bed – there’s no limit. This multi-function cargo box can be customize any way you want.

Audio Roof

• More than just a roof over your head

Here’s the new waterproof sound system available in option. Six 7.7’’ speakers with Bluetooth compatibility, multi-colored LEDs, an RMC amp and a genuine Rockford Fosgate audio receiver to crank up your playlists when you’re out there in the fields herding or baling to the beat of your own drum. Sounds good? You bet!

HVAC

• No sweat: Available climate control

Features an automatic & a variable compressor mode that improves efficiency. Dial in heating, ventilation or air conditioning to keep the cabin temperature exactly how you like and lock in that temperature with the painted full doors.

Equipped for anything

• Integrated pass-through storage

Exclusive full-width under bed storage for cargo, gear, tools, and more. That’s in addition to removable side panels, a dump mechanism, and 100% more loading space than the Defender. Enjoy gimmick-free practicality that’s ready to haul with strength and space to spare.

Specifications

Engine

• Engine Type: Rotax® V-twin

• Power: 82 hp / 69 lb-ft torque

• Cooling: Liquid-cooled

• Displacement: 976 cc

• Fuel System: Intelligent Throttle Control (iTC™) with Electronic Fuel Injection (EFI)

Battery

• Battery: 12 V, 30 A·h

Drivetrain & Transmission

• Drivetrain Modes: Selectable Turf Mode / 2WD / 4WD with Smart-Lok

• Driving Assistance: CVT engine braking | ECO™ / ECO™ Off / Work modes | Speed limiter

• Transmission: PRO-TORQ CVT with Quick Response System (QRS), high-airflow ventilation, and Electronic Drive Belt Protection

• Transmission Gears: Extra-L / H / N / R / P

Steering

• Steering Type: Dynamic Power Steering (DPS™)

• Steering Column: Adjustable tilt steering

Suspension

• Front Suspension: Arched double A-arm with sway bar

• Front Travel: 12 in. (30.5 cm)

• Rear Suspension: Arched TTA with external sway bar

• Rear Travel: 12 in. (30.5 cm)

• Shocks: Twin-tube gas-charged shocks (front & rear)

Brakes

• Front Brakes: Dual 220 mm disc brakes with hydraulic twin-piston calipers

• Rear Brakes: Dual 220 mm disc brakes with hydraulic single-piston calipers

Wheels & Tires

• Wheels: 14 in. cast aluminum

• Front Tires: XPS Trac Force 30 x 9 / 10 x 14 in.

• Rear Tires: XPS Trac Force 30 x 9 / 10 x 14 in.

Dimensions

• Vehicle (LxWxH): 126 x 65 x 81 in. (319 x 165.1 x 252 cm)

• Wheelbase: 83 in. (211.5 cm)

• Ground Clearance: 14 in. (35.6 cm)

• Cargo Box Size: 38 x 54.5 x 12 in. (96.5 x 138.4 x 30.5 cm)

Capacities

• Storage: 12.7 gal (48.1 L)

• Cargo Box Capacity: 1,000 lb (454 kg) | CA: 600 lb (272.2 kg)

• Towing Capacity: 2,500 lb (1,134 kg)

• Payload Capacity: 1,200 lb (544 kg)

• Fuel Tank: 10.6 gal (40 L)

• Tailgate Load Capacity: 250 lb (113.4 kg)

• Seating Capacity: 3

Weight

• Estimated Dry Weight: 1,976 lb (896 kg)

• Winch: 4,500 lb (2,041 kg) with roller fairlead

Features

• Instrumentation: 7.6 in. digital display, keypad, DC outlet (10 A), dual USB ports (10 A)

• Seating: VERSA-PRO bolster bench seats, passenger flip-up seats, adjustable driver seat, reinforced skin

• Protection:

  • XT front bumper

  • HMWPE full skid plate

  • Full hard roof with liner and dome light

  • Full color-match doors with electric windows

  • 3-position full glass tilt-up windshield with wiper/washer

  • Rear glass window

Additional

• Magneto: 850 W

• Cage Type: Profiled cage, ROPS approved

• Lighting: 140 W front LED lights, LED signature lighting, LED tail lights

• Hitch: 2 in. hitch receiver

Warranty

• Factory: 1-Year BRP Limited Warranty

• Extended: B.E.S.T. Warranty – Available up to 30 months
